Focus
Ground Recessed
Litek Architect designed Focus focusing on: quick installation, optimal thermal dissipation, and anti-condensation protection. High-quality materials and precision optics ensure a performing, durable product that integrates easily into any project.
Installation Type
Ground recessed
Body
Lighting body: Die-cast aluminum - Electronics housing: Polyamide
Frame
Extra clear opal tempered glass 15 mm
Seals
EPDM
Screws
Stainless steel A2
Recessed Opal Glass Ø200 - Built-in driver
| Code | Beam | Class | IP | W | Power supply | Control | Fixture | CCT LED |
|---|---|---|---|---|---|---|---|---|
| LA-FC00/HC35VO |
Diffused/110°
|
II | 67 | 12 W | 220-240Vac 50/60Hz | ON/OFF | 370 lm | 2700K |
| LA-FC00/WC35VO |
Diffused/110°
|
II | 67 | 12 W | 220-240Vac 50/60Hz | ON/OFF | 370 lm | 3000K |
| LA-FC00/NC35VO |
Diffused/110°
|
II | 67 | 12 W | 220-240Vac 50/60Hz | ON/OFF | 400 lm | 4000K |
Recessed asymmetric Ø200 - Built-in driver
| Code | Beam | Class | IP | W | Power supply | Control | Fixture | CCT LED |
|---|---|---|---|---|---|---|---|---|
| LA-FC00/HC50AB |
Asymmetric
|
II | 67 | 20 W | 220-240Vac 50/60Hz | ON/OFF | 1757 lm | 2700K |
| LA-FC00/WC50AB |
Asymmetric
|
II | 67 | 20 W | 220-240Vac 50/60Hz | ON/OFF | 1850 lm | 3000K |
| LA-FC00/NC50AB |
Asymmetric
|
II | 67 | 20 W | 220-240Vac 50/60Hz | ON/OFF | 1950 lm | 4000K |
Recessed Ø200 - Built-in driver
| Code | Beam | Class | IP | W | Power supply | Control | Fixture | CCT LED |
|---|---|---|---|---|---|---|---|---|
| LA-FC00/HC50NB |
Narrow/15°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | ON/OFF | 1805 lm | 2700K |
| LA-FC00/HC50MB |
Medium/25°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | ON/OFF | 1843 lm | 2700K |
| LA-FC00/HC50WB |
Wide/36°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | ON/OFF | 1900 lm | 2700K |
| LA-FC00/HC50SW |
Super Wide/60°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | ON/OFF | 1900 lm | 2700K |
| LA-FC00/WC50NB |
Narrow/15°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | ON/OFF | 1900 lm | 3000K |
| LA-FC00/WC50MB |
Medium/25°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | ON/OFF | 1940 lm | 3000K |
| LA-FC00/WC50WB |
Wide/36°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | ON/OFF | 2000 lm | 3000K |
| LA-FC00/WC50SW |
Super Wide/60°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | ON/OFF | 2000 lm | 3000K |
| LA-FC00/NC50NB |
Narrow/15°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | ON/OFF | 2000 lm | 4000K |
| LA-FC00/NC50MB |
Medium/25°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | ON/OFF | 2040 lm | 4000K |
| LA-FC00/NC50WB |
Wide/36°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | ON/OFF | 2100 lm | 4000K |
| LA-FC00/NC50SW |
Super Wide/60°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | ON/OFF | 2100 lm | 4000K |
Recessed DALI Opal Glas Ø200 - Built-in driver
| Code | Beam | Class | IP | W | Power supply | Control | Fixture | CCT LED |
|---|---|---|---|---|---|---|---|---|
| LA-FC00/HD35VO |
Diffused/110°
|
II | 67 | 12 W | 220-240Vac 50/60Hz | DALI-2 integrated | 370 lm | 2700K |
| LA-FC00/WD35VO |
Diffused/110°
|
II | 67 | 12 W | 220-240Vac 50/60Hz | DALI-2 integrated | 370 lm | 3000K |
| LA-FC00/ND35VO |
Diffused/110°
|
II | 67 | 12 W | 220-240Vac 50/60Hz | DALI-2 integrated | 400 lm | 4000K |
Recessed DALI asymmetric Ø200 - Built-in driver
| Code | Beam | Class | IP | W | Power supply | Control | Fixture | CCT LED |
|---|---|---|---|---|---|---|---|---|
| LA-FC00/HD50AB |
Asymmetric
|
II | 67 | 20 W | 220-240Vac 50/60Hz | DALI-2 integrated | 1757 lm | 2700K |
| LA-FC00/WD50AB |
Asymmetric
|
II | 67 | 20 W | 220-240Vac 50/60Hz | DALI-2 integrated | 1850 lm | 3000K |
| LA-FC00/ND50AB |
Asymmetric
|
II | 67 | 20 W | 220-240Vac 50/60Hz | DALI-2 integrated | 1950 lm | 4000K |
Recessed DALI Ø200 - Built-in driver
| Code | Beam | Class | IP | W | Power supply | Control | Fixture | CCT LED |
|---|---|---|---|---|---|---|---|---|
| LA-FC00/HD50NB |
Narrow/15°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | DALI-2 integrated | 1805 lm | 2700K |
| LA-FC00/HD50MB |
Medium/25°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | DALI-2 integrated | 1843 lm | 2700K |
| LA-FC00/HD50WB |
Wide/36°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | DALI-2 integrated | 1900 lm | 2700K |
| LA-FC00/HD50SW |
Super Wide/60°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | DALI-2 integrated | 1900 lm | 2700K |
| LA-FC00/WD50NB |
Narrow/15°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | DALI-2 integrated | 1900 lm | 3000K |
| LA-FC00/WD50MB |
Medium/25°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | DALI-2 integrated | 1940 lm | 3000K |
| LA-FC00/WD50WB |
Wide/36°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | DALI-2 integrated | 2000 lm | 3000K |
| LA-FC00/WD50SW |
Super Wide/60°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | DALI-2 integrated | 2000 lm | 3000K |
| LA-FC00/ND50NB |
Narrow/15°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | DALI-2 integrated | 2000 lm | 4000K |
| LA-FC00/ND50MB |
Medium/25°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | DALI-2 integrated | 2040 lm | 4000K |
| LA-FC00/ND50WB |
Wide/36°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | DALI-2 integrated | 2100 lm | 4000K |
| LA-FC00/ND50SW |
Super Wide/60°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | DALI-2 integrated | 2100 lm | 4000K |
Recessed TRIAC Opal Glas Ø200 - Built-in driver
| Code | Beam | Class | IP | W | Power supply | Control | Fixture | CCT LED |
|---|---|---|---|---|---|---|---|---|
| LA-FC00/HT35VO |
Diffused/110°
|
II | 67 | 12 W | 220-240Vac 50/60Hz | Phase cut dimmable | 370 lm | 2700K |
| LA-FC00/WT35VO |
Diffused/110°
|
II | 67 | 12 W | 220-240Vac 50/60Hz | Phase cut dimmable | 370 lm | 3000K |
| LA-FC00/NT35VO |
Diffused/110°
|
II | 67 | 12 W | 220-240Vac 50/60Hz | Phase cut dimmable | 400 lm | 4000K |
Recessed TRIAC asymmetric Ø200 - Built-in driver
| Code | Beam | Class | IP | W | Power supply | Control | Fixture | CCT LED |
|---|---|---|---|---|---|---|---|---|
| LA-FC00/HT50AB |
Asymmetric
|
II | 67 | 20 W | 220-240Vac 50/60Hz | Phase cut dimmable | 1757 lm | 2700K |
| LA-FC00/WT50AB |
Asymmetric
|
II | 67 | 20 W | 220-240Vac 50/60Hz | Phase cut dimmable | 1850 lm | 3000K |
| LA-FC00/NT50AB |
Asymmetric
|
II | 67 | 20 W | 220-240Vac 50/60Hz | Phase cut dimmable | 1950 lm | 4000K |
Recessed TRIAC Ø200 - Built-in driver
| Code | Beam | Class | IP | W | Power supply | Control | Fixture | CCT LED |
|---|---|---|---|---|---|---|---|---|
| LA-FC00/HT50NB |
Narrow/15°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | Phase cut dimmable | 1805 lm | 2700K |
| LA-FC00/HT50MB |
Medium/25°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | Phase cut dimmable | 1843 lm | 2700K |
| LA-FC00/HT50WB |
Wide/36°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | Phase cut dimmable | 1900 lm | 2700K |
| LA-FC00/HT50SW |
Super Wide/60°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | Phase cut dimmable | 1900 lm | 2700K |
| LA-FC00/WT50NB |
Narrow/15°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | Phase cut dimmable | 1900 lm | 3000K |
| LA-FC00/WT50MB |
Medium/25°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | Phase cut dimmable | 1940 lm | 3000K |
| LA-FC00/WT50WB |
Wide/36°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | Phase cut dimmable | 2000 lm | 3000K |
| LA-FC00/WT50SW |
Super Wide/60°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | Phase cut dimmable | 2000 lm | 3000K |
| LA-FC00/NT50NB |
Narrow/15°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | Phase cut dimmable | 2000 lm | 4000K |
| LA-FC00/NT50MB |
Medium/25°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | Phase cut dimmable | 2040 lm | 4000K |
| LA-FC00/NT50WB |
Wide/36°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | Phase cut dimmable | 2100 lm | 4000K |
| LA-FC00/NT50SW |
Super Wide/60°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | Phase cut dimmable | 2100 lm | 4000K |
Recessed Opal Glass L. 200 - Built-in driver
| Code | Beam | Class | IP | W | Power supply | Control | Fixture | CCT LED |
|---|---|---|---|---|---|---|---|---|
| LA-FC10/HC35VO |
Diffused/110°
|
II | 67 | 12 W | 220-240Vac 50/60Hz | ON/OFF | 370 lm | 2700K |
| LA-FC10/WC35VO |
Diffused/110°
|
II | 67 | 12 W | 220-240Vac 50/60Hz | ON/OFF | 370 lm | 3000K |
| LA-FC10/NC35VO |
Diffused/110°
|
II | 67 | 12 W | 220-240Vac 50/60Hz | ON/OFF | 400 lm | 4000K |
Recessed asymmetric L. 200 - Built-in driver
| Code | Beam | Class | IP | W | Power supply | Control | Fixture | CCT LED |
|---|---|---|---|---|---|---|---|---|
| LA-FC10/HC50AB |
Asymmetric
|
II | 67 | 20 W | 220-240Vac 50/60Hz | ON/OFF | 1757 lm | 2700K |
| LA-FC10/WC50AB |
Asymmetric
|
II | 67 | 20 W | 220-240Vac 50/60Hz | ON/OFF | 1850 lm | 3000K |
| LA-FC10/NC50AB |
Asymmetric
|
II | 67 | 20 W | 220-240Vac 50/60Hz | ON/OFF | 1950 lm | 4000K |
Recessed L. 200 - Built-in driver
| Code | Beam | Class | IP | W | Power supply | Control | Fixture | CCT LED |
|---|---|---|---|---|---|---|---|---|
| LA-FC10/HC50NB |
Narrow/15°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | ON/OFF | 1805 lm | 2700K |
| LA-FC10/HC50MB |
Medium/25°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | ON/OFF | 1843 lm | 2700K |
| LA-FC10/HC50WB |
Wide/36°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | ON/OFF | 1900 lm | 2700K |
| LA-FC10/HC50SW |
Super Wide/60°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | ON/OFF | 1900 lm | 2700K |
| LA-FC10/WC50NB |
Narrow/15°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | ON/OFF | 1900 lm | 3000K |
| LA-FC10/WC50MB |
Medium/25°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | ON/OFF | 1940 lm | 3000K |
| LA-FC10/WC50WB |
Wide/36°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | ON/OFF | 2000 lm | 3000K |
| LA-FC10/WC50SW |
Super Wide/60°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | ON/OFF | 2000 lm | 3000K |
| LA-FC10/NC50NB |
Narrow/15°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | ON/OFF | 2000 lm | 4000K |
| LA-FC10/NC50MB |
Medium/25°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | ON/OFF | 2040 lm | 4000K |
| LA-FC10/NC50WB |
Wide/36°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | ON/OFF | 2100 lm | 4000K |
| LA-FC10/NC50SW |
Super Wide/60°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | ON/OFF | 2100 lm | 4000K |
Recessed DALI Opal Glas L. 200 - Built-in driver
| Code | Beam | Class | IP | W | Power supply | Control | Fixture | CCT LED |
|---|---|---|---|---|---|---|---|---|
| LA-FC10/HD35VO |
Diffused/110°
|
II | 67 | 12 W | 220-240Vac 50/60Hz | DALI-2 integrated | 370 lm | 2700K |
| LA-FC10/WD35VO |
Diffused/110°
|
II | 67 | 12 W | 220-240Vac 50/60Hz | DALI-2 integrated | 370 lm | 3000K |
| LA-FC10/ND35VO |
Diffused/110°
|
II | 67 | 12 W | 220-240Vac 50/60Hz | DALI-2 integrated | 400 lm | 4000K |
Recessed DALI asymmetric L. 200 - Built-in driver
| Code | Beam | Class | IP | W | Power supply | Control | Fixture | CCT LED |
|---|---|---|---|---|---|---|---|---|
| LA-FC10/HD50AB |
Asymmetric
|
II | 67 | 20 W | 220-240Vac 50/60Hz | DALI-2 integrated | 1757 lm | 2700K |
| LA-FC10/WD50AB |
Asymmetric
|
II | 67 | 20 W | 220-240Vac 50/60Hz | DALI-2 integrated | 1850 lm | 3000K |
| LA-FC10/ND50AB |
Asymmetric
|
II | 67 | 20 W | 220-240Vac 50/60Hz | DALI-2 integrated | 1950 lm | 4000K |
Recessed DALI L. 200 - Built-in driver
| Code | Beam | Class | IP | W | Power supply | Control | Fixture | CCT LED |
|---|---|---|---|---|---|---|---|---|
| LA-FC10/HD50NB |
Narrow/15°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | DALI-2 integrated | 1805 lm | 2700K |
| LA-FC10/HD50MB |
Medium/25°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | DALI-2 integrated | 1843 lm | 2700K |
| LA-FC10/HD50WB |
Wide/36°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | DALI-2 integrated | 1900 lm | 2700K |
| LA-FC10/HD50SW |
Super Wide/60°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | DALI-2 integrated | 1900 lm | 2700K |
| LA-FC10/WD50NB |
Narrow/15°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | DALI-2 integrated | 1940 lm | 3000K |
| LA-FC10/WD50MB |
Medium/25°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | DALI-2 integrated | 1900 lm | 3000K |
| LA-FC10/WD50WB |
Wide/36°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | DALI-2 integrated | 2000 lm | 3000K |
| LA-FC10/WD50SW |
Super Wide/60°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | DALI-2 integrated | 2000 lm | 3000K |
| LA-FC10/ND50NB |
Narrow/15°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | DALI-2 integrated | 2000 lm | 4000K |
| LA-FC10/ND50MB |
Medium/25°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | DALI-2 integrated | 2040 lm | 4000K |
| LA-FC10/ND50WB |
Wide/36°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | DALI-2 integrated | 2100 lm | 4000K |
| LA-FC10/ND50SW |
Super Wide/60°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | DALI-2 integrated | 2100 lm | 4000K |
Recessed TRIAC Opal Glas L. 200 - Built-in driver
| Code | Beam | Class | IP | W | Power supply | Control | Fixture | CCT LED |
|---|---|---|---|---|---|---|---|---|
| LA-FC10/HT35VO |
Diffused/110°
|
II | 67 | 12 W | 220-240Vac 50/60Hz | Phase cut dimmable | 370 lm | 2700K |
| LA-FC10/WT35VO |
Diffused/110°
|
II | 67 | 12 W | 220-240Vac 50/60Hz | Phase cut dimmable | 370 lm | 3000K |
| LA-FC10/NT35VO |
Diffused/110°
|
II | 67 | 12 W | 220-240Vac 50/60Hz | Phase cut dimmable | 400 lm | 4000K |
Recessed TRIAC asymmetric L. 200 - Built-in driver
| Code | Beam | Class | IP | W | Power supply | Control | Fixture | CCT LED |
|---|---|---|---|---|---|---|---|---|
| LA-FC10/HT50AB |
Asymmetric
|
II | 67 | 20 W | 220-240Vac 50/60Hz | Phase cut dimmable | 1757 lm | 2700K |
| LA-FC10/WT50AB |
Asymmetric
|
II | 67 | 20 W | 220-240Vac 50/60Hz | Phase cut dimmable | 1850 lm | 3000K |
| LA-FC10/NT50AB |
Asymmetric
|
II | 67 | 20 W | 220-240Vac 50/60Hz | Phase cut dimmable | 1950 lm | 4000K |
Recessed TRIAC L. 200 - Built-in driver
| Code | Beam | Class | IP | W | Power supply | Control | Fixture | CCT LED |
|---|---|---|---|---|---|---|---|---|
| LA-FC10/HT50NB |
Narrow/15°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | Phase cut dimmable | 1805 lm | 2700K |
| LA-FC10/HT50MB |
Medium/25°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | Phase cut dimmable | 1843 lm | 2700K |
| LA-FC10/HT50WB |
Wide/36°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | Phase cut dimmable | 1900 lm | 2700K |
| LA-FC10/HT50SW |
Super Wide/60°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | Phase cut dimmable | 1900 lm | 2700K |
| LA-FC10/WT50NB |
Narrow/15°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | Phase cut dimmable | 1940 lm | 3000K |
| LA-FC10/WT50MB |
Medium/25°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | Phase cut dimmable | 1900 lm | 3000K |
| LA-FC10/WT50WB |
Wide/36°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | Phase cut dimmable | 2000 lm | 3000K |
| LA-FC10/WT50SW |
Super Wide/60°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | Phase cut dimmable | 2000 lm | 3000K |
| LA-FC10/NT50MB |
Narrow/15°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | Phase cut dimmable | 2040 lm | 4000K |
| LA-FC10/NT50NB |
Medium/25°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | Phase cut dimmable | 2000 lm | 4000K |
| LA-FC10/NT50WB |
Wide/36°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | Phase cut dimmable | 2100 lm | 4000K |
| LA-FC10/NT50SW |
Super Wide/60°
|
II | 67 | 20 W | 220-240Vac 50/60Hz | Phase cut dimmable | 2100 lm | 4000K |
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
